XC5VLX330-2FF1760C
| Do pobrania | Download |
|---|---|
| Main description | FPGA Virtex®-5 LX Family 331776 Cells 65nm Technology 1V 1760-Pin FCBGA |
FPGA Virtex®-5 LX Family 331776 Cells 65nm Technology 1V 1760-Pin FCBGA
Informacje podstawowe
- ProducentXilinx
- EURoHSNo (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Crosses 135
- PCNs 15
- MaskPart XC5VLX3302FF1760C%
- IntroductionDate Apr 14, 2006
Parametry
- Copy Protection Yes
- Dedicated DSP 192
- Device Logic Cells 331776
- Device Logic Gates N/A
- Device Logic Units 331776
- Device Number of DLLs/PLLs 18
- Device System Gates N/A
- Digital Control Impedance Yes
- Ethernet MACs N/A
- Family Name Virtex®-5 LX
- Giga Multiply Accumulates per Second 105.6
- I/O Voltage (V) 1.5|1.8|2.5
- In-System Programmability No
- Maximum Differential I/O Pairs N/A
- Maximum Distributed RAM Bits 3502080
- Maximum I/O Performance 1.25Gbps
- Maximum Internal Frequency (MHz) N/A
- Maximum Number of SERDES Channels N/A
- Maximum Number of User I/Os 1200
- Maximum Power Dissipation (mW) N/A
- Maximum Propagation Delay Time (ns) N/A
- Mega Multiply Accumulates per second 105600
- Number of Global Clocks 32
- Number of I/O Banks 33
- Number of Inter Dielectric Layers 12
- Number of Multipliers 384 (25x18)
- Number of Registers N/A
- PCI Blocks N/A
- Process Technology 65nm
- Processor Blocks N/A
- Program Memory Type SRAM
- Programmability No
- RAM Bits (Kbit) 10368
- Reprogrammability Support No
- Shift Registers Utilize LUT
- Speed Grade 2
- Supplier Temperature Grade Commercial
- Temperature Flag Jun
- Tolerant Configuration Interface Voltage (V) 3.3
- Total Number of Block RAM 288
- Tradename Virtex
- Transceiver Blocks N/A
- Transceiver Speed (Gbps) 3.75
- Typical Supply Current (mA) N/A
