TDA1516BQ/N2,112
| Do pobrania | Download |
|---|---|
| Main description | Audio Amp Speaker 1-CH Mono/2-CH Stereo 24W Class-B Automotive 13-Pin DBS13P Bulk |
Audio Amp Speaker 1-CH Mono/2-CH Stereo 24W Class-B Automotive 13-Pin DBS13P Bulk
Informacje podstawowe
- ProducentNXP Semiconductors
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive Yes
Informacje dodatkowe
- Crosses 4
- PCNs 15
- MaskPart TDA1516BQN2%
- IntroductionDate Jul 01, 1994
- AliasParts 935008780112
Parametry
- Amplifier Type Class-B
- Function Speaker
- Input Signal Type Single
- Maximum Dual Supply Voltage (V) N/R
- Maximum Input Bias Current (uA) N/A
- Maximum Input Offset Voltage (mV) N/A
- Maximum Load Resistance (Ohm) 4
- Maximum Output Current (mA) 6000
- Maximum Output Power x Channels @ Load (W) N/A
- Maximum Power Dissipation (mW) 25000
- Maximum Quiescent Current (mA) 80@14.4V
- Maximum Single Supply Voltage (V) 18
- Maximum Supply Current (mA) N/A
- Minimum CMRR (dB) N/A
- Minimum Dual Supply Voltage (V) N/R
- Minimum Single Supply Voltage (V) 6
- Output Signal Type Differential|Single
- Output Type 1-Channel Mono|2-Channel Stereo
- Power Supply Type Single
- Rail to Rail N/A
- Supplier Temperature Grade N/A
- Total Harmonic Distortion Noise N/A
- Typical Dual Supply Voltage (V) N/R
- Typical Gain Bandwidth Product (MHz) N/A
- Typical Output Power x Channels @ Load (W) 24x1@4Ohm|12x2@2Ohm
- Typical PSRR (dB) 80(Min)
- Typical Quiescent Current (mA) 40@14.4V
- Typical Single Supply Voltage (V) 14.4
- Typical Supply Current (mA) N/A
- Typical Voltage Gain (dB) 26
