LTV-247
| Do pobrania | Download |
|---|---|
| Main description | Optocoupler DC-IN 4-CH Transistor DC-OUT 16-Pin SMD T/R |
Optocoupler DC-IN 4-CH Transistor DC-OUT 16-Pin SMD T/R
Informacje podstawowe
- ProducentLite-On Technology
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Inventory 8
- PCNs 7
- MaskPart LTV247%
- IntroductionDate Apr 15, 2010
Parametry
- Common Mode Voltage (V) N/A
- Current Transfer Ratio Test Current (mA) 5
- Input Type DC
- Maximum Collector Current (mA) 50
- Maximum Collector-Emitter Saturation Voltage (mV) 400
- Maximum Collector-Emitter Voltage (V) 80
- Maximum Current Transfer Ratio (%) 600
- Maximum Data Rate N/A
- Maximum Fall Time (us) N/A
- Maximum Forward Current (mA) 50
- Maximum Forward Voltage (V) 1.4
- Maximum Power Dissipation (mW) 170
- Maximum Propagation Delay Time (tPHL) (ns) N/A
- Maximum Propagation Delay Time (tPLH) (ns) N/A
- Maximum Reverse Voltage (V) 6
- Maximum Rise Time (us) N/A
- Maximum Storage Temperature (°C) 150
- Maximum Supply Voltage (V) N/A
- Maximum Working Insulation Voltage (V) N/A
- Minimum Collector Emitter Voltage (V) N/A
- Minimum Common Mode Rejection (kV/us) N/A
- Minimum Current Transfer Ratio (%) 50
- Minimum Forward Voltage (V) N/A
- Minimum Isolation Voltage (Vrms) 3750
- Minimum Storage Temperature (°C) -55
- Number of Channels per Chip 4
- Output Device Transistor
- Output Type DC
- Standard CSA|FIMKO|UL|VDE
- Supplier Temperature Grade N/A
- Typical Bandwidth (MHz) N/A
- Typical Fall Time (us) 3
- Typical Forward Voltage (V) 1.2
- Typical Rise Time (us) 2
