HV1325-2R7156-R
| Do pobrania | Download |
|---|---|
| Main description | Cap Supercap 15F 2.7V -10% to 30% (13.5 X 28.4mm) Radial Aluminum Cylindrical Can 5mm 23uA 0.03 Ohm 1000h 65°C Bulk |
Cap Supercap 15F 2.7V -10% to 30% (13.5 X 28.4mm) Radial Aluminum Cylindrical Can 5mm 23uA 0.03 Ohm 1000h 65°C Bulk
Informacje podstawowe
- ProducentEaton
- EURoHSYes (2011/65/EU, 2015/863)
- Automotive No
Informacje dodatkowe
- Inventory 8
- PCNs 65
- IntroductionDate Jan 10, 2011
Parametry
- Capacitance Value 15F
- Construction Aluminum Cylindrical Can
- Equivalent Series Inductance (nH) N/A
- Equivalent Series Resistance (Ohm) 0.03
- Equivalent Series Resistance Type Ultra Low
- Failure Rate N/R
- Leakage Current (uA) 23
- Lifetime (h) 1000
- Maximum Storage Temperature (°C) N/A
- Military Standard N/R
- Minimum Storage Temperature (°C) N/A
- Package Region World Wide
- Polarity Polar
- Ripple Current (mA) N/A
- Tolerance -10% to 30%
- Tradename PowerStor®
- Voltage 2.7VDC
